Nama Wahi | LC430DGJ-SLA1 |
Waitohu | LG Display |
Rahi | 43 |
Taupānga | TV Sets |
Whakatau | 38403×2160 |
Te tito | a-Si TFT-LCD, CELL |
Tirohanga | |
CR | 1300:1 |
Nga Tae | 1.07B |
Whakamuri | No |
Atanga | EPI |
brand | LG Display |
model | LC430DGJ-SLA1 |
diagonal size | 43 inch |
type | a-Si TFT-LCD, CELL |
pixel format | 3840(3)×2160 [UHD] 103PPI |
configuration | RGBW Vertical Stripe |
active area | 941.184(H)×529.416(V) mm |
outline dim. | 953(H)×543(V) ×1.2(D) mm |
bezel area | - |
treatment | Antiglare (Haze 3%), Hard coating (2H) |
luminance | 0 cd/m² |
contrast ratio | 1300:1 (Typ.) (TM) |
view direction | Symmetry |
response time | 6 (Typ.)(G to G) |
viewing angle | 89/89/89/89 (Min.)(CR≥10) |
operating mode | IPS, Normally Black, Transmissive |
plate thickness | 0.40+0.50 mm |
transmittance | 6.15% (Typ.)(with Polarizer) |
support color | 1.07B |
light source | No B/L |
weight | 1.50Kgs (Typ.) |
designed for | TV Sets |
frame rate | 60Hz |
touch panel | Without |
d-ic detail | COF Built-in 6 source chips |
interface type | EPI , 120 pins Connector |
power supply | 12.7V (Typ.) |
environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
