Nama Wahi | LC370EUD-SDM1 |
Waitohu | LG Display |
Rahi | 37 |
Taupānga | LCTV |
Whakatau | 1920×1080 |
Te tito | LCM |
Tirohanga | 450 |
CR | 1600:1 |
Nga Tae | 16.7M/1.06B |
Whakamuri | WLED |
Atanga | LVDS |
panel brand | LG Display |
panel model | LC370EUD-SDM1 |
panel type | a-Si TFT-LCD , LCM |
panel size | 37 inch |
resolution | 1920(RGB)×1080 , FHD |
display mode | IPS, Normally Black, Transmissive |
active area | 819.36×460.89 mm |
outline | 856.4×501 mm |
surface | Hard coating (3H), Reflection 2.0% (Max.) |
brightness | 450 cd/m² (Typ.) |
contrast ratio | 1600:1 (Typ.) |
display colors | 16.7M/1.06B (8-bit / 8-bit + Dithering), CIE193172% |
response time | 5 (Typ.)(G to G) |
viewing angle | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
frequency | 120Hz+120Hz |
lamp type | WLEDEmbedded (LED Driver) |
signal interface | LVDS (4 ch, 8/10-bit), 92 pins |
input voltage | 12.0V (Typ.) |
application | LCTV |
