| Nama Wahi | LA123WF4-SR09 |
| Waitohu | LG Display |
| Rahi | 12.3 |
| Taupānga | Automotive Display |
| Whakatau | 1920×720 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 800:1 |
| Nga Tae | 16.7M |
| Whakamuri | 8S6P |
| Atanga | RSDS |
| panel brand | LG Display |
| panel model | LA123WF4-SR09 |
| panel size | 12.3" |
| panel type | a-Si TFT-LCD, LCM |
| resolution | 1920(RGB)×720, 167PPI |
| pixel format | RGB Vertical Stripe |
| display area | 292.032(W)×109.512(H) mm |
| bezel opening | 296.03(W)×113.5(H) mm |
| outline size | 310(W)×128(H) ×10.75(D) mm |
| surface | Antiglare, Antireflection |
| brightness | 600 cd/m² (Min.) |
| contrast ratio | 800:1 (Min.) (TM) |
| viewing angle | 89/89/89/89 (Min.)(CR≥10) |
| display mode | IPS, Normally Black, Transmissive |
| best view on | Symmetry |
| response time | 30 (Max.)(G to G); 30 (Typ.)(MPRT) |
| display colors | 16.7M 77% NTSC |
| lamp type | 8S6P WLED , 10K hours , Without Driver |
| frequency | 60Hz |
| touch screen | Without |
| panel weight | - |
| application | Automotive Display |
| signal interface | RSDS (2 Channel) , 110 pins FPC |
| input voltage | 3.3/13.0V (Typ.)(VCC/VDD) |
| environment | Operating Temp.: -40 ~ 85 °C ; Storage Temp.: -40 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
