| Nama Wahi | LA070WV7-SL02 |
| Waitohu | LG Display |
| Rahi | 7.0 |
| Taupānga | Outdoor High Brightn |
| Whakatau | 800×480 |
| Te tito | LCM, a-Si TFT-LCD |
| Tirohanga | |
| CR | 1100:1 |
| Nga Tae | 16.7M |
| Whakamuri | 6S3P |
| Atanga | LVDS |
| manufacturer | LG Display |
| model name | LA070WV7-SL02 |
| screen size | 7.0 inch |
| screen type | LCM, a-Si TFT-LCD |
| pixel number | 800(RGB)×480 (WVGA) 133PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 152.4 × 91.44 (H×V) |
| outline(mm) | 166.4 × 106.2 × 10.7 (H×V×D) |
| bezel area(mm) | 158.4 × 94.2 (H×V) |
| treatment | Antiglare (Haze 25%) |
| luminance | 1000 cd/m² (Typ.) |
| contrast ratio | 1100 : 1 (Typ.) (TM) |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
| response | 16/14 (Typ.)(Tr/Td) ms |
| good view at | Symmetry |
| work mode | IPS, Normally Black, Transmissive |
| color depth | 16.7M 65% NTSC |
| backlight | 6S3P WLED , 30K hours , No Driver |
| mass | 162/167g (Typ./Max.) |
| used for | Outdoor High Brightness Automotive Display |
| refresh rate | 60Hz |
| touchscreen | Without |
| signal type | LVDS (1 ch, 8-bit) , FPC 50 pins |
| voltage supply | 3.3/13/18/-7.5V (Typ.)(DVDD/AVDD/VGH/VGL) |
| max. ratings | Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 5.0G (49.0 m/s²) |
