| Nama Wahi | LA070WV6-SD02 |
| Waitohu | LG Display |
| Rahi | 7.0 |
| Taupānga | Automotive Display |
| Whakatau | 800×480 |
| Te tito | a-Si TFT-LCD , LCM |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | 5S2P |
| Atanga | Parallel |
| panel brand | LG Display |
| panel size | 7.0" |
| resolution | 800(RGB)×480, WVGA, 133PPI |
| display area | 152.4(W)×91.44(H) mm |
| outline size | 166.6(W)×105.8(H) ×10.5(D) mm |
| brightness | 610 cd/m² (Typ.) |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
| best view on | Symmetry |
| display colors | 16.7M 60% NTSC |
| frequency | 60Hz |
| panel weight | 180/185g (Typ./Max.) |
| signal interface | Parallel RGB (1 ch, 6-bit) , 66 pins FPC |
| input voltage | 3.3/13.0/18.5/-7.5V (Typ.)(DVDD/AVDD/VGH/VGL) |
| environment | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -40 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
| panel model | LA070WV6-SD02 |
| panel type | a-Si TFT-LCD , LCM |
| pixel format | RGB Vertical Stripe |
| bezel opening | 155.0(W)×94.0(H) mm |
| surface | Antiglare (Haze 25%), Hard coating (3H) |
| contrast ratio | 1000:1 (Typ.) (TM) |
| display mode | IPS, Normally Black, Transmissive |
| response time | 15/10 (Typ.)(Tr/Td) |
| lamp type | 5S2P WLED , 20K hours , Without Driver |
| touch screen | Without |
| application | Automotive Display |
