| Nama Wahi | LA070WV2-TD01 |
| Waitohu | LG Display |
| Rahi | 7.0 |
| Taupānga | Automotive Display |
| Whakatau | 800×480 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 500:1 |
| Nga Tae | 262K |
| Whakamuri | 9S2P |
| Atanga | Parallel |
| panel brand | LG Display |
| panel model | LA070WV2-TD01 |
| panel size | 7.0" |
| panel type | a-Si TFT-LCD, LCM |
| resolution | 800(RGB)×480, WVGA, 133PPI |
| pixel format | RGB Vertical Stripe |
| display area | 152.4(W)×91.44(H) mm |
| bezel opening | 154.45(W)×93.24(H) mm |
| outline size | 169(W)×103.45(H) mm |
| surface | Antiglare |
| brightness | 550 cd/m² (Typ.) |
| contrast ratio | 500:1 (Typ.) (TM) |
| viewing angle | 70/70/50/60 (Typ.)(CR≥10) |
| display mode | TN, Normally White, Transmissive |
| best view on | - |
| response time | 6/9 (Typ.)(Tr/Td) |
| display colors | 262K 64% NTSC |
| lamp type | 9S2P WLED , Without Driver |
| frequency | 60Hz |
| touch screen | Without |
| panel weight | 165/175g (Typ./Max.) |
| application | Automotive Display |
| signal interface | Parallel RGB (1 ch, 6-bit) , 60 pins FPC |
| input voltage | 3.3/10.0/18.5/-8.5V (Typ.)(DVDD/AVDD/VGH/VGL) |
| environment | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -40 ~ 95 °C |
