| Nama Wahi | KHS038AA1AG-G83 |
| Waitohu | Kyocera |
| Rahi | 3.8 |
| Taupānga | Industrial |
| Whakatau | 240×320 |
| Te tito | LCM , CSTN-LCD |
| Tirohanga | |
| CR | 15:1 |
| Nga Tae | Color |
| Whakamuri | 1 |
| Atanga | Parallel |
| manufacturer | Kyocera |
| screen size | 3.8 inch |
| pixel number | 240(RGB)×320 (QVGA) 105PPI |
| active area(mm) | 57.58 × 76.78 (H×V) |
| luminance | 16 cd/m² (Typ.) |
| viewing angle | 50/45/20/30 (Typ.)(CR≥2) |
| good view at | - |
| color depth | Color |
| mass | - |
| refresh rate | 75Hz |
| signal type | Parallel Data (1ch, 8-bit) FPC |
| voltage supply | 3.3V (Typ.) |
| max. ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| model name | KHS038AA1AG-G83 |
| screen type | LCM , CSTN-LCD |
| arrangement | RGB Vertical Stripe |
| outline(mm) | - |
| contrast ratio | 15 : 1 (Typ.) (TM) |
| response | 250/150 (Typ.)(Tr/Td) ms |
| work mode | STN, Normally Black, Transflective |
| backlight | 1 pcs CCFL , No Driver |
| used for | Industrial |
| touchscreen | - |
