| Nama Wahi | KCS057QV1BH-G20 |
| Waitohu | Kyocera |
| Rahi | 5.7 |
| Taupānga | Industrial |
| Whakatau | 320×240 |
| Te tito | LCM, CSTN-LCD |
| Tirohanga | |
| CR | 40:1 |
| Nga Tae | Color |
| Whakamuri | 1 |
| Atanga | Parallel |
| manufacturer | Kyocera |
| model name | KCS057QV1BH-G20 |
| screen size | 5.7 inch |
| screen type | LCM, CSTN-LCD |
| pixel number | 320(RGB)×240 (QVGA) 70PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 115.2 × 86.4 (H×V) |
| outline(mm) | - |
| luminance | - |
| contrast ratio | 40 : 1 (Typ.) (TM) |
| viewing angle | 50/50/30/30 (Typ.)(CR≥2) |
| response | 220/110 (Typ.)(Tr/Td) ms |
| good view at | - |
| work mode | STN, Normally Black, Transmissive |
| color depth | Color |
| backlight | 1 pcs CCFL , 40K hours , No Driver |
| mass | - |
| used for | Industrial |
| refresh rate | - |
| touchscreen | Without |
| signal type | Parallel Data (1ch, 8-bit) , Connector 15 pins |
