| Nama Wahi | JJ103IA-12A |
| Waitohu | Innolux |
| Rahi | 10.3 |
| Taupānga | Outdoor High Brightn |
| Whakatau | 1920×720 |
| Te tito | a-Si TFT-LCD , LCM |
| Tirohanga | |
| CR | 1300:1 |
| Nga Tae | 16.7M |
| Whakamuri | 4 |
| Atanga | LVDS |
| panel brand | Innolux |
| panel size | 10.3" |
| resolution | 1920(RGB)×720, 200PPI |
| display area | 243.648(W)×91.368(H) mm |
| outline size | 255.24(W)×106.68(H) mm |
| brightness | 800 cd/m² (Typ.) |
| viewing angle | 80/80/80/80 (Min.)(CR≥10) |
| best view on | Symmetry |
| display colors | 16.7M 71% NTSC |
| frequency | 60Hz |
| panel weight | 380g (Max.) |
| signal interface | LVDS (2 ch, 8-bit) , 50 pins Connector |
| input voltage | 3.3V (Typ.) |
| environment | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -40 ~ 90 °C ; Vibration Level: 2.0G (19.6 m/s²) |
| panel model | JJ103IA-12A |
| panel type | a-Si TFT-LCD , LCM |
| pixel format | RGB Vertical Stripe |
| bezel opening | 246.65(W)×94.37(H) mm |
| surface | Antiglare |
| contrast ratio | 1300:1 (Typ.) (TM) |
| display mode | IPS, Normally Black, Transmissive |
| response time | 27 (Typ.)(Tr+Td) |
| lamp type | 4 strings WLED , 10K hours , Without Driver |
| touch screen | Without |
| application | Outdoor High Brightness Automotive Display |
