| Nama Wahi | HT14X12-101 |
| Waitohu | HYDIS |
| Rahi | 14.1 |
| Taupānga | NBPC |
| Whakatau | 1024×768 |
| Te tito | LCM |
| Tirohanga | 130 |
| CR | 200:1 |
| Nga Tae | 262K |
| Whakamuri | CCFL |
| Atanga | LVDS |
| panel brand | HYUNDAI |
| panel model | HT14X12-101 2 Compatible model |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 14.1 inch |
| resolution | 1024(RGB)×768 , XGA |
| display mode | TN, Normally White, Transmissive |
| active area | 285.696×214.272 mm |
| outline | 298.5×227.5×6 mm |
| shape style | Wedge (PCBA Bent, Depth ≥5.2mm) |
| surface | |
| brightness | 130 cd/m² (Typ.) |
| contrast ratio | 200:1 (Typ.) |
| display colors | 262K (6-bit) |
| response time | 20/41 (Max.)(Tr/Td) |
| viewing angle | 40/40/10/30 (Min.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 1 pcsCCFLWithout Driver |
| signal interface | LVDS (1 ch, 6-bit), 20 pins |
| input voltage | 3.3V (Typ.) |
| application | NBPC |
| B141PW03 V1 | AUO | 14.1 | 1440×900 |
| HT14X12-101 | HYDIS | 14.1 | 1024×768 |
| HT14X13-101 | HYDIS | 14.1 | 1024×768 |
| HT14X13-102 | HYDIS | 14.1 | 1024×768 |
| HT14X14-101 | HYDIS | 14.0 | 1024×768 |
| HT14X1B-201 | HYDIS | 14.1 | 1024×768 |
| LP141WP1-TLC3 | LG Display | 14.1 | 1440×900 |
| LT141DEQ8B00 | TOSHIBA | 14.1 | 1440×900 |
| LTN141W1-L02 | Samsung | 14.1 | 1280×800 |
| M141NWW1-102 | IVO | 14.1 | 1280×800 |
| B133EW04 V4 | AUO | 13.3 | 1280×800 |
| B141EW04 V3 | AUO | 14.1 | 1280×800 |
| G075ADE-T01 | Innolux | 7.5 | 1200×900 |
| LP121X04-C2 | LG Display | 12.1 | 1024×768 |
| LP141WP3-TLA1 | LG Display | 14.1 | 1440×900 |
| LP171WP4-TLB4 | LG Display | 17.1 | 1440×900 |
| LTN121AT10-301 | Samsung | 12.1 | 1280×800 |
| LTN154CT04-D01 | Samsung | 15.4 | 1920×1200 |
| LTN156AT01-D02 | Samsung | 15.6 | 1366×768 |
| N154I5-L02 | Innolux | 15.4 | 1280×800 |
