| Nama Wahi | HT14P12-100 |
| Waitohu | HYDIS |
| Rahi | 14.1 |
| Taupānga | NBPC |
| Whakatau | 1400×1050 |
| Te tito | LCM |
| Tirohanga | 150 |
| CR | 200:1 |
| Nga Tae | 262K |
| Whakamuri | CCFL |
| Atanga | LVDS |
| panel brand | BOE HYDIS |
| panel model | HT14P12-100 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 14.1 inch |
| resolution | 1400(RGB)×1050 , SXGA+ |
| display mode | TN, Normally White, Transmissive |
| active area | 285.6×214.2 mm |
| outline | 299×228×5.5 mm |
| shape style | Wedge (PCBA Bent, Depth ≥5.2mm) |
| surface | |
| brightness | 150 cd/m² (Typ.) |
| contrast ratio | 200:1 (Min.) |
| display colors | 262K (6-bit) |
| response time | 25/25 (Max.)(Tr/Td) |
| viewing angle | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 1 pcsCCFLWithout Driver |
| signal interface | LVDS (2 ch, 6-bit), 30 pins |
| input voltage | 3.3V (Typ.) |
| application | NBPC |
