| Nama Wahi | HSD103JPW2-H10 |
| Waitohu | HannStar |
| Rahi | 10.3 |
| Taupānga | Outdoor High Brightn |
| Whakatau | 1920×720 |
| Te tito | LCM , a-Si TFT-LCD |
| Tirohanga | |
| CR | 1500:1 |
| Nga Tae | 16.7M |
| Whakamuri | 4 |
| Atanga | LVDS |
| manufacturer | HannStar |
| screen size | 10.3 inch |
| pixel number | 1920(RGB)×720 200PPI |
| active area(mm) | 243.648 × 91.368 (H×V) |
| bezel area(mm) | 246.7 × 94.4 (H×V) |
| luminance | 1000 cd/m² (Typ.) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| good view at | Symmetry |
| color depth | 16.7M 70% NTSC |
| mass | TBD |
| refresh rate | 60Hz |
| signal type | LVDS (2 ch, 8-bit) , 60 pins FPC |
| voltage supply | 3.3V (Typ.) |
| max. ratings | Storage Temp.: -40 ~ 95 °C Operating Temp.: -40 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| model name | HSD103JPW2-H10 |
| screen type | LCM , a-Si TFT-LCD |
| arrangement | RGB Vertical Stripe |
| outline(mm) | 258.8 × 110 × 17 (H×V×D) |
| treatment | Antiglare, Hard coating (3H) |
| contrast ratio | 1500 : 1 (Typ.) (TM) |
| response | 30 (Max.)(Tr+Td) ms |
| work mode | IPS Pro, Normally Black, Transmissive |
| backlight | 4 strings WLED , 20K hours , No Driver |
| used for | Outdoor High Brightness Automotive Display |
| touchscreen | Without |
| DJ103FA-01A | Innolux | 10.3 | 1920×720 |
