| Nama Wahi | HSD103IPW1-A10-0299 |
| Waitohu | HannStar |
| Rahi | 10.3 |
| Taupānga | Automotive Display |
| Whakatau | 1280×480 |
| Te tito | CELL, a-Si TFT-LCD |
| Tirohanga | |
| CR | 900:1 |
| Nga Tae | 262K/16.7M |
| Whakamuri | No |
| Atanga | |
| manufacturer | HannStar |
| model name | HSD103IPW1-A10-0299 |
| screen size | 10.3 inch |
| screen type | CELL, a-Si TFT-LCD |
| pixel number | 1280(RGB)×480 (DVGA) 133PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 243.84 × 91.44 (H×V) |
| outline(mm) | 253 × 103.3 × 1.25 (H×V×D) |
| bezel area(mm) | - |
| treatment | Antiglare, Hard coating (3H) |
| luminance | 0 cd/m² |
| contrast ratio | 900 : 1 (Typ.) (TM) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| response | 30 (Typ.)(Tr+Td) ms |
| good view at | Symmetry |
| work mode | IPS Pro, Normally Black, Transmissive |
| glass thickness | 0.50+0.50 mm |
| transmissivity | 4.7% (Typ.)(with Polarizer) |
| color depth | 262K/16.7M 70% NTSC |
| backlight | No B/L |
| mass | TBD |
| used for | Automotive Display |
| refresh rate | 60Hz |
| touchscreen | Without |
| Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
