| Nama Wahi | HSD101JFW1-C11 |
| Waitohu | HannStar |
| Rahi | 10.1 |
| Taupānga | Automotive Display |
| Whakatau | 1024×600 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 800:1 |
| Nga Tae | 16.2M |
| Whakamuri | WLED |
| Atanga | LVDS |
| brand | HannStar |
| model | HSD101JFW1-C11 |
| diagonal size | 10.1 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 1024(RGB)×600 [WSVGA] 117PPI |
| configuration | RGB Vertical Stripe |
| active area | 222.72(H)×125.28(V) mm |
| outline dim. | 235(H)×143(V) ×6.3(D) mm |
| bezel area | 226(H)×128.5(V) mm |
| treatment | Hard coating (3H) |
| luminance | 500 cd/m² (Typ.) |
| contrast ratio | 800:1 (Typ.) (TM) |
| view direction | Symmetry |
| response time | 25 (Typ.)(Tr+Td) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| operating mode | IPS Pro, Normally Black, Transflective |
| support color | 16.2M 45% NTSC |
| light source | WLED [6S7P] , 20K hours , W/O Driver |
| weight | 265/275g (Typ./Max.) |
| designed for | Automotive Display |
| frame rate | 60Hz |
| touch panel | Without |
| interface type | LVDS (1 ch, 8-bit) , 60 pins FPC |
| power supply | 3.3/12.5/20/-10V (Typ.)(VDD/AVDD/VGH/VGL) |
| environment | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
