| Nama Wahi | HSD090IHW1-A10 |
| Waitohu | HannStar |
| Rahi | 9.0 |
| Taupānga | Automotive Display |
| Whakatau | 1280×720 |
| Te tito | a-Si TFT-LCD , LCM |
| Tirohanga | |
| CR | 900:1 |
| Nga Tae | 16.7M |
| Whakamuri | 9S3P |
| Atanga | |
| panel brand | HannStar |
| panel size | 9.0" |
| resolution | 1280(RGB)×720, WXGA, 163PPI |
| display area | 198.912(W)×111.888(H) mm |
| outline size | 210.7(W)×124.1(H) ×8.35(D) mm |
| brightness | 600 cd/m² (Typ.) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| best view on | Symmetry |
| display colors | 16.7M 70% NTSC |
| frequency | 60Hz |
| weight | 225/235g (Typ./Max.) |
| panel model | HSD090IHW1-A10 |
| panel type | a-Si TFT-LCD , LCM |
| pixel format | RGB Vertical Stripe |
| bezel opening | 200.9(W)×113.8(H) mm |
| surface | Antiglare, Hard coating (3H) |
| contrast ratio | 900:1 (Typ.) (TM) |
| display mode | IPS Pro, Normally Black, Transmissive |
| response time | 30 (Typ.)(Tr+Td) |
| lamp type | 9S3P WLED , 30K hours , Without Driver |
| touch screen | Without |
| application | Automotive Display |
