| Nama Wahi | HSD070JWW1-A20 |
| Waitohu | HannStar |
| Rahi | 7.0 |
| Taupānga | Automotive Display |
| Whakatau | 1280×768 |
| Te tito | a-Si TFT-LCD , LCM |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | HannStar |
| panel size | 7.0" |
| resolution | 1280(RGB)×768, WXGA, 213PPI |
| display area | 152.448(W)×91.4688(H) mm |
| brightness | - |
| viewing angle | - |
| best view on | Symmetry |
| display colors | 16.7M |
| frequency | 60Hz |
| panel weight | - |
| signal interface | LVDS (1 ch, 8-bit) + SPI , 60 pins FPC |
| input voltage | 3.3V (Typ.) |
| environment | Operating Temp.: -40 ~ 85 °C ; Storage Temp.: -40 ~ 90 °C |
| panel model | HSD070JWW1-A20 |
| panel type | a-Si TFT-LCD , LCM |
| pixel format | RGB Vertical Stripe |
| bezel opening | - |
| contrast ratio | 1000:1 (Min.) (TM) |
| display mode | IPS Pro, Normally Black, Transmissive |
| response time | 25 (Max.)(Tr+Td) |
| lamp type | WLED |
| touch screen | - |
| application | Automotive Display |
