| Nama Wahi | HB125WX1-200 |
| Waitohu | BOE |
| Rahi | 12.5 |
| Taupānga | NBPC |
| Whakatau | 1366×768 |
| Te tito | LCM |
| Tirohanga | 200 |
| CR | 500:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | eDP |
| panel brand | BOE |
| panel model | HB125WX1-200 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 12.5 inch |
| resolution | 1366(RGB)×768 , WXGA |
| display mode | TN, Normally White, Transmissive |
| active area | 276.615×155.52 mm |
| outline | 290.5×181.4×3 mm |
| shape style | Slim (PCBA Flat, Depth ≤3.2mm) |
| surface | Antiglare |
| brightness | 200 cd/m² (Typ.) |
| contrast ratio | 500:1 (Typ.) |
| display colors | 262K (6-bit), CIE193145% |
| response time | 16 (Typ.)(Tr+Td) |
| viewing angle | 45/45/20/40 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 9S3PWLEDEmbedded (LED Driver) |
| signal interface | eDP (1 Lane), 30 pins |
| input voltage | 3.3V (Typ.) |
| application | NBPC |
