| Nama Wahi | GV101WXB-NN0-3GP0 |
| Waitohu | BOE |
| Rahi | 10.1 |
| Taupānga | Industrial |
| Whakatau | 1280×800 |
| Te tito | a-Si TFT-LCD, CELL |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | No |
| Atanga | LVDS |
| panel brand | BOE |
| panel model | GV101WXB-NN0-3GP0 |
| panel size | 10.1" |
| panel type | a-Si TFT-LCD, CELL |
| resolution | 1280(RGB)×800, WXGA, 149PPI |
| pixel format | RGB Vertical Stripe |
| display area | 216.96(W)×135.6(H) mm |
| bezel opening | - |
| outline size | 221.96(W)×144.43(H) ×1.06(D) mm |
| surface | Without Polarizer, Hard coating |
| brightness | 0 cd/m² |
| contrast ratio | 1000:1 (Typ.) (TM) |
| viewing angle | 80/80/80/80 (Typ.)(CR≥10) |
| display mode | ADS, Normally Black, Transmissive |
| best view on | Symmetry |
| response time | 35 (Typ.)(Tr+Td) |
| display colors | 16.7M 50% NTSC |
| lamp type | No B/L |
| frequency | 60Hz |
| touch screen | Without |
| driver ic | COG Built-in 2 source chips |
| panel weight | - |
| application | Industrial |
| signal interface | LVDS (1 ch, 8-bit) , 40 pins Connector |
| input voltage | 3.3V (Typ.) |
| environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
