| Nama Wahi | G270ZAN01.3 |
| Waitohu | AUO |
| Rahi | 27.0 |
| Taupānga | Industrial Medical I |
| Whakatau | 3840×2160 |
| Te tito | LCM , a-Si TFT-LCD |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | 10S8P |
| Atanga | eDP |
| manufacturer | AUO |
| model name | G270ZAN01.3 |
| screen size | 27.0 inch |
| screen type | LCM , a-Si TFT-LCD |
| pixel number | 3840(RGB)×2160 (UHD) 163PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 596.16 × 335.34 (H×V) |
| outline(mm) | 630 × 368.2 × 19.8 (H×V×D) |
| bezel area(mm) | 602.0 × 340.4 (H×V) |
| treatment | Antiglare, Hard coating (3H) |
| luminance | 350 cd/m² (Typ.) |
| contrast ratio | 1000 : 1 (Typ.) (TM) |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
| response | 16/25 (Typ./Max.)(Tr+Td) ms |
| good view at | Symmetry |
| work mode | AHVA, Normally Black, Transmissive |
| color depth | 16.7M 99% Adobe RGB |
| backlight | 10S8P WLED , 30K hours , No Driver |
| mass | 3.30Kgs (Typ.) |
| used for | Industrial Medical Imaging |
| refresh rate | 60Hz |
| touchscreen | Without |
| signal type | eDP (4 Lanes) , HBR2 (5.4G/lane) , 51 pins Connector |
| voltage supply | 12.0V (Typ.) |
| max. ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| LM270WF1-TLD1 | LG Display | 27.0 | 1920×1080 |
| LM270WF5-SLB1 | LG Display | 27.0 | 1920×1080 |
| LM270WF5-SLM1 | LG Display | 27.0 | 1920×1080 |
| LM270WQ1-SDF1 | LG Display | 27.0 | 2560×1440 |
| LM270WQ3-SLB2 | LG Display | 27.0 | 2560×1440 |
| LTM270DL06 | Samsung | 27.0 | 2560×1440 |
| LTM270HT03 | Samsung | 27.0 | 1920×1080 |
| M270DAN01.0 | AUO | 27.0 | 2560×1440 |
| M270DTN01.1 | AUO | 27.0 | 2560×1440 |
| M270H1-L01 | Innolux | 27.0 | 1920×1080 |
