| Nama Wahi | G270HAN01.2 |
| Waitohu | AUO |
| Rahi | 27.0 |
| Taupānga | Industrial |
| Whakatau | 1920×1080 |
| Te tito | LCM, a-Si TFT-LCD |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | 22S4P |
| Atanga | LVDS |
| manufacturer | AUO |
| model name | G270HAN01.2 |
| screen size | 27.0 inch |
| screen type | LCM, a-Si TFT-LCD |
| pixel number | 1920(RGB)×1080 (FHD) 81PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 597.888 × 336.312 (H×V) |
| outline(mm) | 611.48 × 355.81 × 13.3 (H×V×D) |
| bezel area(mm) | 601.49 × 339.91 (H×V) |
| treatment | Antiglare |
| luminance | 400 cd/m² (Typ.) |
| contrast ratio | 1000 : 1 (Typ.) (TM) |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
| response | 14 (Typ.)(Tr+Td) ms |
| good view at | Symmetry |
| work mode | AHVA, Normally Black, Transmissive |
| color depth | 16.7M 72% NTSC |
| backlight | 22S4P WLED , 50K hours , No Driver |
| mass | 2.87Kgs (Typ.) |
| used for | Industrial |
| refresh rate | 60Hz |
| touchscreen | Without |
| signal type | LVDS (2 ch, 8-bit) , Connector 30 pins |
| voltage supply | 5.0V (Typ.) |
| max. ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
