| Nama Wahi | G238HAN01.1 |
| Waitohu | AUO |
| Rahi | 23.8 |
| Taupānga | Industrial Medical I |
| Whakatau | 1920×1080 |
| Te tito | LCM , a-Si TFT-LCD |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | 18S4P |
| Atanga | LVDS |
| manufacturer | AUO |
| screen size | 23.8 inch |
| pixel number | 1920(RGB)×1080 (FHD) 92PPI |
| active area(mm) | 527.04 × 296.46 (H×V) |
| bezel area(mm) | 530.2 × 299.6 (H×V) |
| luminance | 400 cd/m² (Typ.) |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
| good view at | Symmetry |
| color depth | 16.7M 70% NTSC |
| mass | 2.30Kgs (Typ.) |
| refresh rate | 60Hz |
| signal type | LVDS (2 ch, 8-bit) , 30 pins Connector |
| voltage supply | 5.0V (Typ.) |
| max. ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| model name | G238HAN01.1 |
| screen type | LCM , a-Si TFT-LCD |
| arrangement | RGB Vertical Stripe |
| outline(mm) | 543 × 317.4 × 11.65 (H×V×D) |
| treatment | Antiglare, Hard coating (3H) |
| contrast ratio | 1000 : 1 (Typ.) (TM) |
| response | 14 (Typ.)(G to G) ms |
| work mode | AHVA, Normally Black, Transmissive |
| backlight | 18S4P WLED , 50K hours , No Driver |
| used for | Industrial Medical Imaging |
| touchscreen | Without |
