| Nama Wahi | G229HAN01.0 |
| Waitohu | AUO |
| Rahi | 22.9 |
| Taupānga | Industrial Stretched |
| Whakatau | 1920×165 |
| Te tito | a-Si TFT-LCD , LCM |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | |
| panel brand | AUO |
| panel size | 22.9" |
| resolution | 1920(RGB)×165, 84PPI |
| display area | 578.88(W)×49.7475(H) mm |
| outline size | 587.08(W)×62.05(H) ×10.71(D) mm |
| brightness | 500 cd/m² (Typ.) |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
| best view on | Symmetry |
| display colors | 16.7M 72% NTSC |
| frequency | 60Hz |
| weight | 460g (Typ.) |
| panel model | G229HAN01.0 |
| panel type | a-Si TFT-LCD , LCM |
| pixel format | RGB Vertical Stripe |
| bezel opening | 580.88(W)×51.75(H) mm |
| surface | Antiglare, Hard coating (3H) |
| contrast ratio | 1000:1 (Typ.) (TM) |
| display mode | AHVA, Normally Black, Transmissive |
| response time | 13/12 (Typ.)(Tr/Td) |
| lamp type | WLED , 70K hours , With LED Driver |
| touch screen | Without |
| application | Industrial Stretched Bar LCD |
