Nama Wahi | G215HAN01.4 |
Waitohu | AUO |
Rahi | 21.5 |
Taupānga | Industrial Gaming |
Whakatau | 1920×1080 |
Te tito | LCM, a-Si TFT-LCD |
Tirohanga | |
CR | 1000:1 |
Nga Tae | 16.7M |
Whakamuri | WLED |
Atanga | LVDS |
manufacturer | AUO |
model name | G215HAN01.4 |
screen size | 21.5 inch |
screen type | LCM, a-Si TFT-LCD |
pixel number | 1920(RGB)×1080 (FHD) 102PPI |
arrangement | RGB Vertical Stripe |
active area(mm) | 476.064 × 267.786 (H×V) |
outline(mm) | 497.6 × 292.2 × 11 (H×V×D) |
bezel area(mm) | 479.8 × 271.3 (H×V) |
treatment | Antiglare, Hard coating (3H) |
luminance | - |
contrast ratio | 1000 : 1 (Typ.) (TM) |
viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
response | 12/10 (Typ.)(Tr/Td) ms |
good view at | Symmetry |
work mode | AHVA, Normally Black, Transmissive |
color depth | 16.7M |
backlight | WLED , No Driver |
mass | - |
used for | Industrial Gaming |
refresh rate | 60Hz |
touchscreen | Without |
signal type | LVDS (2 ch, 8-bit) , Connector 30 pins |
voltage supply | 5.0V (Typ.) |
max. ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
