| Nama Wahi | G190EG02 V104 |
| Waitohu | AUO |
| Rahi | 19.0 |
| Taupānga | Industrial Medical I |
| Whakatau | 1280×1024 |
| Te tito | LCM , a-Si TFT-LCD |
| Tirohanga | |
| CR | 2000:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| manufacturer | AUO |
| screen size | 19.0 inch |
| pixel number | 1280(RGB)×1024 (SXGA) 86PPI |
| active area(mm) | 376.32 × 301.056 (H×V) |
| bezel area(mm) | 380.32 × 305.06 (H×V) |
| luminance | 350 cd/m² (Typ.) |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
| good view at | Symmetry |
| color depth | 16.7M 70% NTSC |
| mass | 1.74Kgs (Typ.) |
| refresh rate | 60Hz |
| signal type | LVDS (2 ch, 8-bit) , 30 pins Connector |
| voltage supply | 5.0V (Typ.) |
| max. ratings | Storage Temp.: -20 ~ 70 °C Operating Temp.: -15 ~ 70 °C |
| model name | G190EG02 V104 |
| screen type | LCM , a-Si TFT-LCD |
| arrangement | RGB Vertical Stripe |
| outline(mm) | 396 × 324 × 15.8 (H×V×D) |
| treatment | Antiglare |
| contrast ratio | 2000 : 1 (Typ.) (TM) |
| response | 15/5 (Typ.)(Tr/Td) ms |
| work mode | MVA, Normally Black, Transmissive |
| backlight | WLED , 50K hours , With LED Driver |
| used for | Industrial Medical Imaging |
| touchscreen | Without |
