| Nama Wahi | G190EAN01.6 |
| Waitohu | AUO |
| Rahi | 19.0 |
| Taupānga | Industrial Medical I |
| Whakatau | 1280×1024 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| brand | AUO |
| model | G190EAN01.6 |
| diagonal size | 19.0 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 1280(RGB)×1024 [SXGA] 86PPI |
| configuration | RGB Vertical Stripe |
| active area | 376.32(H)×301.056(V) mm |
| outline dim. | 396(H)×324(V) ×15.8(D) mm |
| bezel area | 380.32(H)×305.06(V) mm |
| treatment | Antiglare |
| luminance | 1000 cd/m² (Typ.) |
| contrast ratio | 1000:1 (Typ.) (TM) |
| view direction | Symmetry |
| response time | 13/12 (Typ.)(Tr/Td) |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
| operating mode | AHVA, Normally Black, Transmissive |
| support color | 16.7M 72% NTSC |
| light source | WLED , 50K hours , With LED Driver |
| weight | 1.70±0.15Kgs |
| designed for | Industrial Medical Imaging Outdoor High Brightness |
| frame rate | 60Hz |
| touch panel | Without |
| interface type | LVDS (2 ch, 8-bit) |
| power supply | 5.0V (Typ.) |
| environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
