| Nama Wahi | G190EAN01.3 |
| Waitohu | AUO |
| Rahi | 19.0 |
| Taupānga | Industrial Medical I |
| Whakatau | 1280×1024 |
| Te tito | LCM, a-Si TFT-LCD |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| manufacturer | AUO |
| model name | G190EAN01.3 |
| screen size | 19.0 inch |
| screen type | LCM, a-Si TFT-LCD |
| pixel number | 1280(RGB)×1024 (SXGA) 86PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 376.32 × 301.056 (H×V) |
| outline(mm) | 396 × 324 × 15.8 (H×V×D) |
| bezel area(mm) | 380.32 × 305.06 (H×V) |
| treatment | Antiglare |
| luminance | 330 cd/m² (Typ.) |
| contrast ratio | 1000 : 1 (Typ.) (TM) |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
| response | 13/12 (Typ.)(Tr/Td) ms |
| good view at | Symmetry |
| work mode | AHVA, Normally Black, Transmissive |
| color depth | 16.7M 72% NTSC |
| backlight | WLED , 50K hours , With LED Driver |
| mass | 1.70±0.15Kgs |
| used for | Industrial Medical Imaging |
| refresh rate | 60Hz |
| touchscreen | Without |
| signal type | LVDS (2 ch, 8-bit) , Connector 30 pins |
| voltage supply | 5.0V (Typ.) |
| max. ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| G190EAN01.0 | AUO | 19.0 | 1280×1024 |
| G190EG01 V0 | AUO | 19.0 | 1280×1024 |
| G190EG01 V1 | AUO | 19.0 | 1280×1024 |
| G190EG01 V2 | AUO | 19.0 | 1280×1024 |
| G190EG02 V0 | AUO | 19.0 | 1280×1024 |
| G190EG02 V1 | AUO | 19.0 | 1280×1024 |
| G190ETN01.0 | AUO | 19.0 | 1280×1024 |
| G190ETN01.2 | AUO | 19.0 | 1280×1024 |
| G190ETN01.4 | AUO | 19.0 | 1280×1024 |
| G190ETN02.0 | AUO | 19.0 | 1280×1024 |
