| Nama Wahi | G156HAB02.5 |
| Waitohu | AUO |
| Rahi | 15.6 |
| Taupānga | Industrial |
| Whakatau | 1920×1080 |
| Te tito | a-Si TFT-LCD, Assemb |
| Tirohanga | |
| CR | 800:1 |
| Nga Tae | 16.2M |
| Whakamuri | WLED |
| Atanga | eDP |
| brand | AUO |
| model | G156HAB02.5 |
| diagonal size | 15.6 inch |
| type | a-Si TFT-LCD, Assembly |
| pixel format | 1920(RGB)×1080 [FHD] 141PPI |
| configuration | RGB Vertical Stripe |
| active area | 344.16(H)×193.59(V) mm |
| outline dim. | - |
| bezel area | - |
| treatment | Hard coating (5H) |
| luminance | - |
| contrast ratio | 800:1 (Typ.) (TM) |
| view direction | Symmetry |
| response time | 25 (Typ.)(Tr+Td) |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
| operating mode | - |
| support color | 16.2M |
| light source | WLED , 50K hours , With LED Driver |
| weight | - |
| designed for | Industrial |
| frame rate | 60Hz |
| touch panel | On-Cell Touch |
| interface type | eDP (2 Lanes) , eDP1.2 |
| power supply | 3.3V (Typ.) |
| environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
