| Nama Wahi | G156HAB01.0 |
| Waitohu | AUO |
| Rahi | 15.6 |
| Taupānga | Industrial |
| Whakatau | 1920×1080 |
| Te tito | a-Si TFT-LCD , Assem |
| Tirohanga | |
| CR | 800:1 |
| Nga Tae | 16.2M |
| Whakamuri | WLED |
| Atanga | eDP |
| panel brand | AUO |
| panel size | 15.6" |
| resolution | 1920(RGB)×1080, FHD, 141PPI |
| display area | 344.16(W)×193.59(H) mm |
| outline size | 361(W)×227(H) ×4.9(D) mm |
| brightness | 300 cd/m² (Typ.) |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
| best view on | Symmetry |
| display colors | 16.2M 45% NTSC |
| frequency | 60Hz |
| panel weight | 620g (Max.) |
| signal interface | eDP (2 Lanes) , eDP1.2 , 40 pins Connector |
| input voltage | 3.3V (Typ.) |
| environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| panel model | G156HAB01.0 |
| panel type | a-Si TFT-LCD , Assembly |
| pixel format | RGB Vertical Stripe |
| bezel opening | - |
| surface | Hard coating (7H) |
| contrast ratio | 800:1 (Typ.) (TM) |
| display mode | - |
| response time | 25 (Typ.)(Tr+Td) |
| lamp type | WLED , 30K hours , With LED Driver |
| touch screen | On-Cell Touch |
| application | Industrial |
| G156HAN01.0 | AUO | 15.6 | 1920×1080 |
| G156HTD01.0 | AUO | 15.6 | 1920×1080 |
| G156HTN01.0 | AUO | 15.6 | 1920×1080 |
| G156HTN02.0 | AUO | 15.6 | 1920×1080 |
| G156HTN02.1 | AUO | 15.6 | 1920×1080 |
| LP156WF1-TLF4 | LG Display | 15.6 | 1920×1080 |
| LP156WF7-SPB2 | LG Display | 15.6 | 1920×1080 |
| LTN156AT36-W01 | Samsung | 15.6 | 1366×768 |
| N156BGE-E21 | Innolux | 15.6 | 1366×768 |
| NV156FHM-N41 | BOE | 15.6 | 1920×1080 |
