Nama Wahi | G150XVN01.2 |
Waitohu | AUO |
Rahi | 15.0 |
Taupānga | Industrial Medical I |
Whakatau | 1024×768 |
Te tito | a-Si TFT-LCD , LCM |
Tirohanga | |
CR | 1500:1 |
Nga Tae | 262K/16.2M |
Whakamuri | WLED |
Atanga | |
brand | AUO |
diagonal size | 15.0 inch |
pixel format | 1024(RGB)×768 [XGA] 85PPI |
active area | 304.128(H)×228.096(V) mm |
bezel area | 307.2(H)×231.1(V) mm |
luminance | 400 cd/m² (Typ.) |
view direction | Symmetry |
viewing angle | 88/88/88/88 (Typ.)(CR≥10) |
support color | 262K/16.2M 72% NTSC |
weight | TBD |
frame rate | 60Hz |
model | G150XVN01.2 |
type | a-Si TFT-LCD , LCM |
configuration | RGB Vertical Stripe |
outline dim. | 326.5(H)×253.5(V) mm |
treatment | Antiglare, Hard coating (3H) |
contrast ratio | 1500:1 (Typ.) (TM) |
response time | 20/15 (Typ.)(Tr/Td) |
operating mode | MVA, Normally Black, Transmissive |
light source | WLED , 50K hours , With LED Driver |
designed for | Industrial Medical Imaging |
touch panel | Without |
