Nama Wahi | G150XTN06.B |
Waitohu | AUO |
Rahi | 15.0 |
Taupānga | Industrial Outdoor H |
Whakatau | 1024×768 |
Te tito | LCM , a-Si TFT-LCD |
Tirohanga | |
CR | 800:1 |
Nga Tae | 262K/16.2M |
Whakamuri | WLED |
Atanga | |
manufacturer | AUO |
screen size | 15.0 inch |
pixel number | 1024(RGB)×768 (XGA) 85PPI |
active area(mm) | 304.128 × 228.096 (H×V) |
bezel area(mm) | 311.9 × 236.85 (H×V) |
luminance | 800 (Typ.)(cd/m²) |
viewing angle | 80/80/70/80 (Typ.)(CR≥10) |
good view at | - |
color depth | 262K/16.2M 60% NTSC |
mass | 1.00Kgs (Max.) |
refresh rate | 60Hz |
model name | G150XTN06.B |
screen type | LCM , a-Si TFT-LCD |
arrangement | RGB Vertical Stripe |
outline(mm) | 326.5 × 253.5 × 10 (H×V×D) |
treatment | Antireflection |
contrast ratio | 800 : 1 (Typ.) (TM) |
work mode | TN, Normally White, Transmissive |
response | 5.7/2.3 (Typ.)(Tr/Td) ms |
backlight | WLED , 50K hours , With LED Driver |
used for | Industrial Outdoor High Brightness |
touchscreen | Without |
