| Nama Wahi | G150XTN06.9 |
| Waitohu | AUO |
| Rahi | 15.0 |
| Taupānga | Industrial Outdoor H |
| Whakatau | 1024×768 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 800:1 |
| Nga Tae | 262K/16.2M |
| Whakamuri | WLED |
| Atanga | LVDS |
| brand | AUO |
| model | G150XTN06.9 |
| diagonal size | 15.0 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 1024(RGB)×768 [XGA] 85PPI |
| configuration | RGB Vertical Stripe |
| active area | 304.128(H)×228.096(V) mm |
| outline dim. | 326.5(H)×253.5(V) ×10(D) mm |
| bezel area | 311.9(H)×236.85(V) mm |
| treatment | Antiglare |
| luminance | 1600 cd/m² (Typ.) |
| contrast ratio | 800:1 (Typ.) (TM) |
| view direction | - |
| response time | 5.7/2.3 (Typ.)(Tr/Td) |
| viewing angle | 80/80/70/80 (Typ.)(CR≥10) |
| operating mode | TN, Normally White, Transmissive |
| support color | 262K/16.2M 60% NTSC |
| light source | WLED , 50K hours , With LED Driver |
| weight | 1.00Kgs (Max.) |
| designed for | Industrial Outdoor High Brightness |
| frame rate | 60Hz |
| touch panel | Without |
| interface type | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| power supply | 3.3V (Typ.) |
| environment | Operating Temperature: -30 ~ 70 °C ; Storage Temperature: -30 ~ 70 °C |
