Nama Wahi | G150XTN03.7 |
Waitohu | AUO |
Rahi | 15.0 |
Taupānga | Industrial |
Whakatau | 1024×768 |
Te tito | a-Si TFT-LCD , LCM |
Tirohanga | |
CR | 500:1 |
Nga Tae | 262K/16.2M |
Whakamuri | WLED |
Atanga | |
panel brand | AUO |
panel size | 15.0" |
resolution | 1024(RGB)×768, XGA, 85PPI |
display area | 304.128(W)×228.096(H) mm |
outline size | 326.5(W)×253.5(H) ×10(D) mm |
brightness | 250 cd/m² (Typ.) |
viewing angle | 45/45/20/40 (Typ.)(CR≥10) |
best view on | - |
display colors | 262K/16.2M 60% NTSC |
frequency | 60Hz |
weight | 1.02Kgs (Max.) |
panel model | G150XTN03.7 |
panel type | a-Si TFT-LCD , LCM |
pixel format | RGB Vertical Stripe |
bezel opening | 313.55(W)×237.25(H) mm |
surface | Antiglare, Hard coating (3H) |
contrast ratio | 500:1 (Typ.) (TM) |
display mode | TN, Normally White, Transmissive |
response time | 6/2 (Typ.)(Tr/Td) |
lamp type | WLED , 50K hours , With LED Driver |
touch screen | Without |
application | Industrial |
