Nama Wahi | G150XNE-L02 |
Waitohu | Innolux |
Rahi | 15.0 |
Taupānga | Industrial Gaming |
Whakatau | 1024×768 |
Te tito | a-Si TFT-LCD, LCM |
Tirohanga | |
CR | 2500:1 |
Nga Tae | 262K/16.2M |
Whakamuri | WLED |
Atanga | LVDS |
brand | Innolux |
model | G150XNE-L02 |
diagonal size | 15.0 inch |
type | a-Si TFT-LCD, LCM |
pixel format | 1024(RGB)×768 [XGA] 85PPI |
configuration | RGB Vertical Stripe |
active area | 304.128(H)×228.096(V) mm |
outline dim. | 326.5(H)×253.5(V) ×9.6(D) mm |
bezel area | 307.4(H)×231.3(V) mm |
treatment | Antiglare, Hard coating (3H) |
luminance | 350 cd/m² (Typ.) |
contrast ratio | 2500:1 (Typ.) (TM) |
view direction | Symmetry |
response time | 13/5 (Typ.)(Tr/Td) |
viewing angle | 88/88/88/88 (Typ.)(CR≥10) |
operating mode | NPVA, Normally Black, Transmissive |
support color | 262K/16.2M 72% NTSC |
light source | WLED , 70K hours , With LED Driver |
weight | 0.97/1.00Kgs (Typ./Max.) |
designed for | Industrial Gaming |
frame rate | 60Hz |
touch panel | Without |
interface type | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
power supply | 3.3V (Typ.) |
environment | Operating Temperature: -30 ~ 70 °C ; Storage Temperature: -40 ~ 70 °C |
