| Nama Wahi | G150XAN01.2 |
| Waitohu | AUO |
| Rahi | 15.0 |
| Taupānga | Industrial |
| Whakatau | 1024×768 |
| Te tito | LCM, a-Si TFT-LCD |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 16.2M |
| Whakamuri | WLED |
| Atanga | LVDS |
| manufacturer | AUO |
| model name | G150XAN01.2 |
| screen size | 15.0 inch |
| screen type | LCM, a-Si TFT-LCD |
| pixel number | 1024(RGB)×768 (XGA) 85PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 304.128 × 228.096 (H×V) |
| outline(mm) | 326.5 × 253.5 × 6.8 (H×V×D) |
| bezel area(mm) | 309.9 × 236.3 (H×V) |
| treatment | Antiglare, Hard coating (3H) |
| luminance | 500 cd/m² (Typ.) |
| contrast ratio | 1000 : 1 (Typ.) (TM) |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
| response | 25 (Typ.)(Tr+Td) ms |
| good view at | Symmetry |
| work mode | AHVA, Normally Black, Transmissive |
| color depth | 16.2M 60% NTSC |
| backlight | WLED , 50K hours , With LED Driver |
| mass | 660g (Max.) |
| used for | Industrial |
| refresh rate | 60Hz |
| touchscreen | Without |
| signal type | LVDS (1 ch, 8-bit) , Connector 30 pins |
| voltage supply | 3.3V (Typ.) |
| max. ratings | Storage Temp.: -20 ~ 70 °C Operating Temp.: -20 ~ 70 °C |
