| Nama Wahi | G150XAN01.0 |
| Waitohu | AUO |
| Rahi | 15.0 |
| Taupānga | Industrial |
| Whakatau | 1024×768 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 16.2M |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | AUO |
| panel model | G150XAN01.0 |
| panel size | 15.0" |
| panel type | a-Si TFT-LCD, LCM |
| resolution | 1024(RGB)×768, XGA, 85PPI |
| pixel format | RGB Vertical Stripe |
| display area | 304.128(W)×228.096(H) mm |
| bezel opening | 309.9(W)×236.3(H) mm |
| outline size | 326.5(W)×253.5(H) ×9(D) mm |
| surface | Antiglare, Hard coating (3H) |
| brightness | 350 cd/m² (Typ.) |
| contrast ratio | 1000:1 (Typ.) (TM) |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
| display mode | AHVA, Normally Black, Transmissive |
| best view on | Symmetry |
| response time | 25 (Typ.)(Tr+Td) |
| display colors | 16.2M 60% NTSC |
| lamp type | WLED , 50K hours , With LED Driver |
| frequency | 60Hz |
| touch screen | Without |
| panel weight | 920g (Max.) |
| application | Industrial |
| signal interface | LVDS (1 ch, 8-bit) , 20 pins Connector |
| input voltage | 3.3V (Typ.) |
| environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -20 ~ 70 °C |
