| Nama Wahi | G070VAN01.0 |
| Waitohu | AUO |
| Rahi | 7.0 |
| Taupānga | Industrial |
| Whakatau | 800×480 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 1300:1 |
| Nga Tae | 262K/16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| brand | AUO |
| model | G070VAN01.0 |
| diagonal size | 7.0 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 800×480(RGB) [WVGA] 133PPI |
| configuration | RGB Horizontal Stripe |
| active area | 152.4(H)×91.44(V) mm |
| outline dim. | 166.6(H)×107(V) ×10(D) mm |
| bezel area | 154.2(H)×93.24(V) mm |
| treatment | Antiglare |
| luminance | 480 cd/m² (Typ.) |
| contrast ratio | 1300:1 (Typ.) (TM) |
| view direction | Symmetry |
| response time | 11/19 (Max.)(Tr/Td) |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
| operating mode | AHVA, Normally Black, Transmissive |
| support color | 262K/16.7M 70% NTSC |
| light source | WLED [7S2P] , 50K hours , W/O Driver |
| weight | 175±10%g |
| designed for | Industrial |
| frame rate | 60Hz |
| touch panel | Without |
| interface type | LVDS (1 ch, 6/8-bit) , 30 pins Connector |
| power supply | 3.3V (Typ.) |
| environment | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -30 ~ 80 °C |
