| Nama Wahi | EV121X0M-N10 |
| Waitohu | BOE |
| Rahi | 12.1 |
| Taupānga | Industrial |
| Whakatau | 1024×768 |
| Te tito | a-Si TFT-LCD , LCM |
| Tirohanga | |
| CR | 1200:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| brand | BOE |
| diagonal size | 12.1 inch |
| pixel format | 1024(RGB)×768 [XGA] 105PPI |
| active area | 245.76(H)×184.32(V) mm |
| bezel area | 249(H)×187.5(V) mm |
| luminance | 500 cd/m² (Typ.) |
| view direction | Symmetry |
| viewing angle | 88/88/88/88 (Typ.)(CR≥10) |
| support color | 16.7M 72% NTSC |
| weight | 520g (Max.) |
| frame rate | 60Hz |
| interface type | LVDS (1 ch, 8-bit) , 20 pins Connector |
| power supply | 3.3V (Typ.) |
| environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| model | EV121X0M-N10 |
| type | a-Si TFT-LCD , LCM |
| configuration | RGB Vertical Stripe |
| outline dim. | 260.5(H)×204(V) ×9.2(D) mm |
| treatment | - |
| contrast ratio | 1200:1 (Typ.) (TM) |
| response time | 25 (Typ.)(Tr+Td) |
| operating mode | ADS, Normally Black, Transmissive |
| light source | WLED , 50K hours , With LED Driver |
| designed for | Industrial |
| touch panel | Without |
