| Nama Wahi | EV121WXM-N12 |
| Waitohu | BOE |
| Rahi | 12.1 |
| Taupānga | Medical Imaging |
| Whakatau | 1280×800 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 1200:1 |
| Nga Tae | 262K/16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| brand | BOE |
| model | EV121WXM-N12 |
| diagonal size | 12.1 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 1280(RGB)×800 [WXGA] 124PPI |
| configuration | RGB Vertical Stripe |
| active area | 261.12(H)×163.2(V) mm |
| outline dim. | 277.7(H)×180.6(V) ×9.2(D) mm |
| bezel area | 264.12(H)×166.2(V) mm |
| treatment | Antiglare (Haze 25%) |
| luminance | 500 cd/m² (Typ.) |
| contrast ratio | 1200:1 (Typ.) (TM) |
| view direction | Symmetry |
| response time | 30 (Typ.)(Tr+Td) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| operating mode | ADS, Normally Black, Transmissive |
| support color | 262K/16.7M 100% sRGB |
| light source | WLED [12S4P] , 50K hours , With LED Driver |
| weight | TBD |
| designed for | Medical Imaging |
| frame rate | 60Hz |
| touch panel | Without |
| interface type | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| power supply | 3.3V (Typ.) |
| environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| AA121SP01 | Mitsubishi | 12.1 | 800×600 |
| AA121TD01-DE3 | Mitsubishi | 12.1 | 1280×800 |
| B121EW07 V1 | AUO | 12.1 | 1280×800 |
| B121EW08 V0 | AUO | 12.1 | 1280×800 |
| B121EW09 V0 | AUO | 12.1 | 1280×800 |
| FLC31SVC6S-17 | Fujitsu | 12.1 | 800×600 |
| LQ121S1DG42 | SHARP | 12.1 | 800×600 |
| LQ121S1LG45 | SHARP | 12.1 | 800×600 |
| LTD121KM1K | TOSHIBA | 12.1 | 1400×1050 |
| LTM12C318S | TOSHIBA | 12.1 | 1024×768 |
