| Nama Wahi | EV101WUM-N20 |
| Waitohu | BOE |
| Rahi | 10.1 |
| Taupānga | Medical Imaging |
| Whakatau | 1920×1200 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 900:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| brand | BOE |
| model | EV101WUM-N20 |
| diagonal size | 10.1 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 1920(RGB)×1200 [WUXGA] 224PPI |
| configuration | RGB Vertical Stripe |
| active area | 216.806(H)×135.504(V) mm |
| outline dim. | 229.45(H)×149.22(V) mm |
| luminance | 600 cd/m² (Typ.) |
| contrast ratio | 900:1 (Typ.) (TM) |
| view direction | Symmetry |
| response time | 30 (Typ.)(Tr+Td) |
| viewing angle | 80/80/80/80 (Typ.)(CR≥10) |
| operating mode | ADS, Normally Black, Transmissive |
| support color | 16.7M 72% NTSC |
| light source | WLED , W/O Driver |
| weight | - |
| designed for | Medical Imaging |
| frame rate | 60Hz |
| touch panel | Without |
| interface type | LVDS (1 ch, 8-bit) , 45 pins Connector |
| power supply | 3.3V (Typ.) |
| environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -25 ~ 80 °C |
