| Nama Wahi | EMA-101402-01 |
| Waitohu | eMagin |
| Rahi | 0.77 |
| Taupānga | HMD VR AR |
| Whakatau | 1280×1024 |
| Te tito | OLED, Si-OLED |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | Grayscale(G) |
| Whakamuri | self |
| Atanga | Parallel |
| manufacturer | eMagin |
| model name | EMA-101402-01 |
| screen size | 0.77 inch |
| screen type | OLED, Si-OLED |
| pixel number | 1280(LCR)×1024 (SXGA) 2116PPI |
| arrangement | LCR Vertical Stripe |
| active area(mm) | 15.36 × 12.29 (H×V) |
| outline(mm) | 22.9 × 16.4 (H×V×D) |
| luminance | 5000 cd/m² (Typ.) |
| contrast ratio | 1000 : 1 (Min.) (TM) |
| viewing angle | - |
| response | - |
| good view at | Symmetry |
| work mode | - |
| color depth | Grayscale(G) |
| backlight | self |
| mass | 2.50g (Typ.) |
| used for | HMD VR AR |
| refresh rate | 85Hz |
| touchscreen | Without |
| signal type | Parallel RGB , Connector 50 pins |
| voltage supply | 2.5/5/-1.4/-2.0V (Typ.)(VDD/VAN/VCOM/VPG) |
| max. ratings | Storage Temp.: -55 ~ 90 °C Operating Temp.: -45 ~ 70 °C |
