| Nama Wahi | EMA-101204-05 |
| Waitohu | eMagin |
| Rahi | 0.63 |
| Taupānga | HMD VR AR |
| Whakatau | 1280×1024 |
| Te tito | Si-OLED, OLED |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | self |
| Atanga | LVDS |
| panel brand | eMagin |
| panel model | EMA-101204-05 |
| panel size | 0.63" |
| panel type | Si-OLED, OLED |
| resolution | 1280(RGB)×1024, SXGA, 2619PPI |
| pixel format | RGB Vertical Stripe |
| display area | 12.4(W)×9.945(H) mm |
| bezel opening | - |
| outline size | 19.5(W)×14.8(H) mm |
| surface | - |
| brightness | 700 cd/m² (Typ.) |
| contrast ratio | 1000:1 (Typ.) (TM) |
| viewing angle | - |
| display mode | - |
| best view on | Symmetry |
| response time | - |
| display colors | 16.7M 52% NTSC |
| lamp type | self |
| frequency | - |
| touch screen | Without |
| panel weight | 3.00g (Max.) |
| application | HMD VR AR |
| signal interface | LVDS (1 ch, 8-bit) , 30 pins Connector |
| input voltage | 5/1.8/-1.5V (Typ.)(VDC/VDD/VPG) |
| environment | Operating Temp.: -45 ~ 70 °C ; Storage Temp.: -55 ~ 90 °C |
