| Nama Wahi | EMA-101126-01 |
| Waitohu | eMagin |
| Rahi | 0.59 |
| Taupānga | HMD VR AR |
| Whakatau | 800×600 |
| Te tito | OLED, Si-OLED |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | Grayscale |
| Whakamuri | self |
| Atanga | Parallel |
| manufacturer | eMagin |
| model name | EMA-101126-01 |
| screen size | 0.59 inch |
| screen type | OLED, Si-OLED |
| pixel number | 800(LCR)×600 (SVGA) 1693PPI |
| arrangement | LCR Vertical Stripe |
| active area(mm) | 12 × 9 (H×V) |
| outline(mm) | 18 × 16 × 5.4 (H×V×D) |
| luminance | 900 cd/m² (Typ.) |
| contrast ratio | 1000 : 1 (Typ.) (TM) |
| viewing angle | - |
| response | - |
| good view at | Symmetry |
| work mode | - |
| color depth | Grayscale 52% NTSC |
| backlight | self |
| mass | 2.00g (Typ.) |
| used for | HMD VR AR |
| refresh rate | 60Hz |
| touchscreen | Without |
| signal type | Parallel RGB (1 ch, 8-bit) , Connector 40 pins |
| voltage supply | 1.8/5.0V (Typ.)(VDD1.8/VDD5) |
| max. ratings | Storage Temp.: -55 ~ 90 °C Operating Temp.: -45 ~ 70 °C |
