| Nama Wahi | EMA-100810-01 |
| Waitohu | eMagin |
| Rahi | 0.86 |
| Taupānga | HMD VR AR |
| Whakatau | 1920×1200 |
| Te tito | OLED , Si-OLED |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | self |
| Atanga | LVDS |
| manufacturer | eMagin |
| screen size | 0.86 inch |
| pixel number | 1920(RGB)×1200 (WUXGA) 2645PPI |
| active area(mm) | 18.432 × 11.52 (H×V) |
| luminance | 140 cd/m² (Typ.) |
| viewing angle | - |
| good view at | Symmetry |
| color depth | 16.7M 48% NTSC |
| mass | 3.00g |
| refresh rate | 85Hz |
| signal type | LVDS , 40 pins Connector |
| voltage supply | 1.8/5.0/-1.5V (Typ.)(VDD/VAN/VPG) |
| max. ratings | Storage Temp.: -55 ~ 90 °C Operating Temp.: -45 ~ 70 °C |
| model name | EMA-100810-01 |
| screen type | OLED , Si-OLED |
| arrangement | RGB Vertical Stripe |
| outline(mm) | 26.05 × 17.35 × 5.44 (H×V×D) |
| contrast ratio | 1000 : 1 (Min.) (TM) |
| response | - |
| work mode | - |
| backlight | self |
| used for | HMD VR AR |
| touchscreen | Without |
