Nama Wahi | ED060SCN |
Waitohu | E Ink |
Rahi | 6.0 |
Taupānga | EBK |
Whakatau | 600×800 |
Te tito | EPD |
Tirohanga | |
CR | |
Nga Tae | Grayscale |
Whakamuri | No B/L |
Atanga | Parallel Data |
panel brand | PVI |
panel model | ED060SCN |
panel type | EPD , EPD |
panel size | 6.0 inch |
resolution | 600×800 , SVGA |
active area | 90.6×122.4 mm |
outline | 101.8×138.4 mm |
surface | Antiglare, Hard coating |
brightness | |
contrast ratio | 12:1 (Typ.)(Reflective) |
display colors | Grayscale (4-bit) |
viewing angle | |
signal interface | Parallel Data (8-bit), 34 pins |
input voltage | 3.3V (Typ.) |
application | EBK |
A050VVN01.0 | AUO | 5.0 | 480×800 |
EC080SC2 | E Ink | 8.0 | |
ED060SCF | E Ink | 6.0 | 600×800 |
ED060SCG | E Ink | 6.0 | 600×800 |
ED060SCN | E Ink | 6.0 | 600×800 |
ED060XH2 | E Ink | 6.0 | 758×1024 |
ED097OC1 | E Ink | 9.7 | 1200×825 |
LB050S01-RD01 | LG Display | 5.0 | 800×600 |
LB060S01-FD01 | LG Display | 6.0 | 800×600 |
PQ 3Qi-01 | Pixel Qi | 10.1 | 1024×600 |
