| Nama Wahi | E1393AA61.C |
| Waitohu | EDO |
| Rahi | 1.4 |
| Taupānga | Wearable Round Displ |
| Whakatau | 400×400 |
| Te tito | AM-OLED, OLED |
| Tirohanga | |
| CR | 10000:1 |
| Nga Tae | 16.7M |
| Whakamuri | self |
| Atanga | MIPI |
| panel brand | EDO |
| panel model | E1393AA61.C |
| panel size | 1.4" |
| panel type | AM-OLED, OLED |
| resolution | 400(RGB)×400, 287PPI |
| pixel format | RGB Vertical Stripe |
| display area | 35.4(W)×35.4(H) mm |
| bezel opening | - |
| outline size | 38.6(W)×40.5(H) ×0.73(D) mm |
| surface | - |
| brightness | 300 cd/m² (Typ.) |
| contrast ratio | 10000:1 (Typ.) (TM) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥200) |
| display mode | - |
| best view on | Symmetry |
| response time | 2 (Typ.)(Tr+Tf) |
| display colors | 16.7M 100% NTSC |
| lamp type | self |
| frequency | 60Hz |
| touch screen | Without |
| driver ic | COFBuilt-in RM67162 |
| panel weight | 2.00g (Typ.) |
| application | Wearable Round Display |
| signal interface | MIPI (1 data lane) , 20 pins Connector |
| input voltage | 1.8/2.8/4.6/-2.4V (Typ.)(VDDIO/VCI/ELVDD/ELVSS) |
| environment | Operating Temp.: -20 ~ 60 °C ; Storage Temp.: -30 ~ 70 °C |
