| Nama Wahi | DV460FHM-NV2 |
| Waitohu | BOE |
| Rahi | 46 |
| Taupānga | Video Wall |
| Whakatau | 1920×1080 |
| Te tito | LCM , a-Si TFT-LCD |
| Tirohanga | |
| CR | 1200:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| manufacturer | BOE |
| screen size | 46 inch |
| pixel number | 1920(RGB)×1080 (FHD) 47PPI |
| active area(mm) | 1018.08 × 572.67 (H×V) |
| bezel area(mm) | - |
| luminance | 500 cd/m² (Typ.) |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
| good view at | Symmetry |
| color depth | 16.7M 95% sRGB |
| splicing seam | 0.9 mm (active to active seam) |
| refresh rate | 60Hz |
| signal type | LVDS (2 ch, 8-bit) , 51 pins Connector |
| voltage supply | 12.0V (Typ.) |
| max. ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| model name | DV460FHM-NV2 |
| screen type | LCM , a-Si TFT-LCD |
| arrangement | RGB Vertical Stripe |
| outline(mm) | 1018.96 × 573.55 × 58.3 (H×V×D) |
| treatment | Antiglare (Haze 25%), Hard coating (2H) |
| contrast ratio | 1200 : 1 (Typ.) (TM) |
| response | 8 (Typ.)(G to G) ms |
| work mode | ADS, Normally Black, Transmissive |
| backlight | WLED , 50K hours , With LED Driver |
| used for | Video Wall |
| touchscreen | Without |
| HV460WUC-200 | BOE | 46 | 1920×1080 |
| LSC460HW01 | Samsung | 46 | 1920×1080 |
| LTA460HM03 | Samsung | 46 | 1920×1080 |
| LTA460HM06 | Samsung | 46 | 1920×1080 |
| LTA460HQ23 | Samsung | 46 | 1920×1080 |
| LTF460HF08 | Samsung | 46 | 1920×1080 |
| T460HW03 VF | AUO | 46 | 1920×1080 |
| T460HW04 V0 | AUO | 46 | 1920×1080 |
| T460HW08 V0 | AUO | 46 | 1920×1080 |
| V460H1-LS2 | Innolux | 46 | 1920×1080 |
