| Nama Wahi | DMF-50174 |
| Waitohu | OPTREX |
| Rahi | 5.7 |
| Taupānga | Industrial |
| Whakatau | 320×240 |
| Te tito | STN-LCD, LCM |
| Tirohanga | |
| CR | |
| Nga Tae | Monochrome |
| Whakamuri | CCFL |
| Atanga | Parallel |
| brand | OPTREX |
| model | DMF-50174 |
| diagonal size | 5.7 inch |
| type | STN-LCD, LCM |
| pixel format | 320×240 [QVGA] 70PPI |
| configuration | Rectangle |
| active area | 115.17(H)×86.37(V) mm |
| outline dim. | 174(H)×112(V) ×14(D) mm |
| bezel area | 122.0(H)×92.0(V) mm |
| treatment | - |
| view direction | - |
| response time | - |
| viewing angle | - |
| operating mode | STN |
| support color | Monochrome |
| light source | CCFL , W/O Driver |
| weight | - |
| designed for | Industrial |
| frame rate | 70Hz |
| touch panel | Without |
| interface type | Parallel Data (1ch, 4-bit) , 14 pins Connector |
| power supply | 5.0V (Typ.) |
| environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| C555001 | SII | 5.7 | 320×240 |
| CLAA057VC01CW | CPT | 5.7 | 640×480 |
| DMF-50174ZNB-FW | Kyocera | 5.7 | 320×240 |
| DMF-50773NB-FW | Kyocera | 5.4 | 240×128 |
| DMF-50773NF-FW | Kyocera | 5.4 | 240×128 |
| DMF-50840NB-FW | Kyocera | 5.7 | 320×240 |
| DMF-51043NFU-FW-1 | Kyocera | 9.4 | 640×480 |
| LTA057A344F | TOSHIBA | 5.7 | 320×240 |
| TCG057QVLAC-G00 | Kyocera | 5.7 | 320×240 |
| TX14D12VM1CBA | KOE | 5.7 | 320×240 |
