| Nama Wahi | CLAA069LAA1CW |
| Waitohu | CPT |
| Rahi | 7.0 |
| Taupānga | Automotive Display |
| Whakatau | 800×480 |
| Te tito | LCM, a-Si TFT-LCD |
| Tirohanga | |
| CR | |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | |
| manufacturer | CPT |
| model name | CLAA069LAA1CW |
| screen size | 7.0 inch |
| screen type | LCM, a-Si TFT-LCD |
| pixel number | 800(RGB)×480 (WVGA) 134PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 156.6 × 81.6 (H×V) |
| outline(mm) | - |
| viewing angle | 75/75/60/70 (Typ.)(CR≥10) |
| response | 20 (Typ.)(Tr+Td) ms |
| good view at | 6 o'clock |
| work mode | TN, Normally White, Transmissive |
| color depth | 262K |
| backlight | WLED |
| mass | - |
| used for | Automotive Display |
| refresh rate | 60Hz |
| touchscreen | Without |
