Nama Wahi | CC500PV6D |
Waitohu | PANDA |
Rahi | 50 |
Taupānga | TV Sets |
Whakatau | 3840×2160 |
Te tito | Oxide TFT-LCD, CELL |
Tirohanga | |
CR | 6000:1 |
Nga Tae | 1.07B |
Whakamuri | No |
Atanga | USI-T |
panel brand | PANDA |
panel model | CC500PV6D |
panel size | 50" |
panel type | Oxide TFT-LCD, CELL |
resolution | 3840(RGB)×2160, UHD, 89PPI |
pixel format | RGB Vertical Stripe |
display area | 1095.8(W)×616.41(H) mm |
bezel opening | - |
outline size | 1105.84(W)×627.91(H) ×1.37(D) mm |
surface | Antiglare (Haze 2.3%), Hard coating (3H) |
brightness | 0 cd/m² |
contrast ratio | 6000:1 (Typ.) (TM) |
viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
display mode | UV2A, Normally Black, Transmissive |
best view on | Symmetry |
response time | 8 (Typ.)(G to G) |
glass depth | 0.50+0.50 mm |
transmissivity | 5.0% (Typ.)(with Polarizer) |
display colors | 1.07B 70% NTSC |
lamp type | No B/L |
frequency | 60Hz |
touch screen | Without |
driver ic | COF Built-in 12 source chips |
panel weight | 2.15Kgs (Typ.) |
application | TV Sets |
signal interface | USI-T , 96 pins Connector |
environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 65 °C |
