| Nama Wahi | C123HAN02.5 |
| Waitohu | AUO |
| Rahi | 12.3 |
| Taupānga | Automotive Display |
| Whakatau | 1920×720 |
| Te tito | LCM, a-Si TFT-LCD |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | 8S4P |
| Atanga | |
| manufacturer | AUO |
| model name | C123HAN02.5 |
| screen size | 12.3 inch |
| screen type | LCM, a-Si TFT-LCD |
| pixel number | 1920(RGB)×720 167PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 292.032 × 109.512 (H×V) |
| outline(mm) | 310.75 × 129.86 × 16.23 (H×V×D) |
| bezel area(mm) | 293.94 × 111.42 (H×V) |
| treatment | Antiglare |
| luminance | 600 cd/m² (Min.) |
| contrast ratio | 1000 : 1 (Typ.) (TM) |
| viewing angle | 80/80/80/80 (Typ.)(CR≥10) |
| response | 15/45 (Typ.)(Tr/Td) ms |
| good view at | Symmetry |
| work mode | AHVA, Normally Black, Transmissive |
| color depth | 16.7M 75% NTSC |
| backlight | 8S4P WLED , 10K hours , No Driver |
| mass | 570±57g |
| used for | Automotive Display |
| refresh rate | 60Hz |
| touchscreen | Without |
| Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
